English Translation of Title:
Bushing for Water Jet Cutting Machine Parts – 38 x 25, Male-to-Female, Model No. 10079432-Bushing-38-x-25-MF-Water-Jet-Parts.927.3-1

Introduction, Application, Features, and Maintenance:

This component is a high-pressure reducing bushing with a male-to-female thread configuration, designed for water jet cutting systems. It connects two high-pressure components of different sizes, reducing from a larger male port to a smaller female port.

Application:
Used to adapt and connect high-pressure lines or fittings with mismatched thread sizes in water jet cutting machines, typically installed between the pump, cutting head, or other hydraulic components where a size reduction from male to female is required.

Features:

• Rated for extreme pressures common in water jet cutting, up to 6,000 bar (87,000 psi).

• Male-to-female (MF) configuration allows direct size reduction without additional adapters.

• Reduces from 38 mm interface to 25 mm interface, enabling compatibility across different system sections.

• Manufactured from high-strength, corrosion-resistant material suitable for abrasive water jet media.

• Compact design minimizes additional leak points in the high-pressure circuit.

Maintenance:

• Regularly inspect the bushing body, threads, and sealing surfaces for signs of erosion, cracking, or thread damage.

• Check for high-pressure leakage at both connection ends during operation.

• Replace immediately if any surface pitting, deformed threads, or pressure loss is detected.

• Always use compatible seals or washers as required by the specific connection type.

• Follow specified torque values when tightening male and female ends.
