201601-xx P-II-Step Nozzle Assembly

Short Description:

Direct waterjet supplier and factory, help maintain and solve waterjet technical problems, customize water jet solutions, provide robotic waterjet, 3D abrasive waterjet, as well as waterjet cutter heads parts and waterjet parts for KMT/FLOW/BHDT/TECHNI/RESATO/OMAX waterjet

INQUIRY

Details

Product Name: P-II Step Nozzle Assembly (Part No. 201601-xx)

Description:
The P-II Step Nozzle Assembly is a cutting head component designed for abrasive waterjet systems. It features a specialized “stepped” internal geometry that creates multiple stages or chambers for mixing water and abrasive before the jet exits the focusing tube. This design is engineered to produce a more coherent cutting stream for specific applications. The -xx suffix denotes various orifice diameter options (e.g., .010, .011 inches).

Applications:

Mounts in the P-II series cutting head, housing the ruby or diamond orifice.
Forms the initial waterjet for cutting metal, stone, and composites.
Fits P-II nozzle bodies and standard high-pressure manifolds.

Features:

Step Design: Internal stepped geometry for enhanced water-abrasive mixing in specific models.
Standard Interface: Compatible with industry-standard 3/4-16 threaded connections.
Orifice Versatility: Available in multiple sizes to match pump flow rates and cutting requirements.

Maintenance:

Jet Quality: Replace immediately if the low-pressure water stream is scattered or split.
Installation: Tighten the retaining nut to the specified torque; over-tightening can crack the jewel.
Depressurization: Always fully depressurize the waterjet system and follow lockout/tagout procedures before replacement.
