Product Name: JE Mount Nozzle Assembly (P-IIT Series) / Part No. 201920-xx

Description:
This component is a nozzle assembly specifically designed for JE (Jet Edge) style waterjet cutting systems. The "P-IIT" designation signifies a specific generation of mounting geometry engineered to fit certain intensifier pumps or cutting head adapters. The -xx suffix indicates that this assembly is available with various orifice diameters (e.g., .010, .013, .014 inches) to suit different pump flow rates and cutting requirements.

Applications:

• Mounts directly onto compatible P-IIT series intensifier pumps or cutting head manifolds.

• Secures the ruby or diamond orifice to generate the initial waterjet.

• Serves as the interface between the high-pressure water supply and the mixing chamber.

Features:

• JE Style Compatibility: Adheres to specific dimensional standards for a leak-free fit with JE style components.

• Precision Orifice Mounting: Ensures the jewel nozzle is perfectly centered for a coherent jet.

• Material: Constructed from high-grade stainless steel for corrosion resistance and longevity.

Maintenance:

• Replacement Indicator: Replace the assembly immediately if the low-pressure water stream is scattered or split, indicating a worn orifice.

• Installation: When installing, apply a thin layer of anti-seize to the threads and tighten to the manufacturer’s specified torque to prevent galling or leaks.

• Seal Check: Always inspect the sealing O-ring for damage or wear prior to reassembly.

• Depressurization: Always fully depressurize the waterjet system and follow lockout/tagout procedures before servicing.
