Product ID: 05077292 – Setscrew (for Autoline™ I Cutting Head Assembly)

Description:
This component is a setscrew, also known as a grub screw, designed for use in Autoline™ I abrasive waterjet cutting head assemblies. It is a small, threaded fastener without a protruding head, typically featuring a hex socket drive. This setscrew is used to secure and position internal components within the cutting head, such as the orifice retaining mechanism or alignment features.

Applications:

• Used in Autoline™ I waterjet cutting heads to secure or lock internal components such as the orifice holder, retaining sleeves, or alignment pins.

• Installed into threaded holes within the nozzle body or cap assembly to prevent unintended rotation or movement of critical aligned parts.

• Suitable for ultra-high pressure waterjet systems operating at 60,000 PSI (approximately 4,137 bar).

Features:

• Constructed from high-strength, corrosion-resistant stainless steel or hardened alloy steel to withstand vibration and mechanical stress.

• Hex socket drive (Allen drive) allows for secure tightening and removal using a hex key in confined spaces.

• Typically features a cup point, cone point, or flat point depending on the specific application within the cutting head assembly.

• Precision-machined threads ensure proper fit and consistent clamping force.

• Compact, headless design allows the setscrew to sit flush with or below the surface of the mating component.

Maintenance:

• Fully depressurize the waterjet system and follow lockout/tagout procedures before loosening or removing any setscrew.

• Use the correct size hex key (Allen wrench) to avoid stripping the hex socket; ensure the key is fully seated before applying torque.

• Inspect the hex socket for rounding or damage; replace any setscrew with a stripped or damaged drive.

• Inspect threads for signs of wear, galling, corrosion, or stretching before reuse.

• Clean the setscrew with a soft cloth and compatible solvent to remove debris, old thread-locking compound, or corrosion.

• During reassembly, apply manufacturer-recommended thread-locking compound (e.g., medium strength) to prevent loosening from vibration.

• Tighten the setscrew to the specific torque value provided in the equipment service manual.

• Do not reuse setscrews that have been over-torqued, show signs of thread deformation, or have damaged drive sockets.

• When replacing a lost or damaged setscrew, ensure the replacement matches the original thread size, length, point type, and material specification.
