English Translation of Title:
Water Jet Cutting Machine Parts – 2-Way Angle Fitting, Model No. 10079275-Water-Jet-Parts-2-Way-Angle-38.916.3-1

Introduction, Application, Features, and Maintenance:

This component is a 2-way angle fitting designed for high-pressure water jet cutting systems. It changes the direction of high-pressure flow at a specific angle while maintaining a two-port connection.

Application:
Used to redirect high-pressure water or abrasive slurry flow in water jet cutting machines, typically installed in confined spaces where a straight connection is not feasible or where directional change is required between components.

Features:

• Rated for extreme pressures common in water jet cutting, up to 6,000 bar (87,000 psi).

• Precision angle design allows smooth flow redirection with minimal turbulence.

• Two-port configuration maintains simple in-line functionality while accommodating directional changes.

• Constructed from high-strength, corrosion-resistant material suitable for abrasive water jet media.

• Compact body enables installation in tight machine layouts.

Maintenance:

• Regularly inspect the fitting body and threads for signs of erosion, cracking, or wear.

• Check for any leakage around the connection points.

• Replace immediately if surface pitting, thread damage, or pressure loss is detected.

• Follow specified torque values when tightening connections.

• Use only compatible seals and washers during reassembly.
