Product Name: HP Tubing Clamp Set / High-Pressure Tube Mounting Pair (Part No. 400082-1)

Description:
The HP Tubing Clamp Set (400082-1) is a matched pair of mounting brackets used to secure high-pressure (HP) water lines to the frame or motion system of a waterjet cutter. The set typically consists of two identical halves that bolt together around the tube, isolating it from machine vibration and preventing fatigue failure of the rigid stainless steel plumbing. It is rated for systems up to 60,000 PSI (4,137 bar).

Applications:

• Securing 1/4 inch or 3/8 inch HP tubing along the Z-axis or gantry to prevent whipping.

• Mounting high-pressure lines to the machine chassis or cable carrier systems.

• Dampening mechanical vibration caused by intensifier pump pulsation.

Features:

• Corrosion-Resistant Material: Manufactured from stainless steel or zinc-plated steel to resist moisture and abrasive dust.

• Vibration Dampening: Often features a rubber or polyurethane insert to cushion the metal tube without causing abrasion.

• Precision Alignment: Designed to hold the tubing securely without crushing the high-pressure walls.

• Pair Configuration: Sold as a "set" (top and bottom halves) with specific bolt holes for chassis mounting.

Maintenance:

• Inspect for Wear: Regularly check the rubber insert for cracking or hardening, which reduces vibration dampening.

• Torque Check: Verify the clamp bolts are tight enough to hold the tube but not so tight as to deform the tubing outer diameter.

• Full Depressurization: Always fully depressurize the waterjet system before loosening clamps to prevent uncontrolled tube movement.

• Replace as Set: If the clamp halves are worn or corroded, replace both halves simultaneously to ensure a proper fit.
